| Quantity: | |
|---|---|
HZ0157QVPTS01-A0
200*320
23.4*38.5*2.2
21.36*33.79
21.36*33.79
ST7789
The full name of TFT is Thin Film Transistor. Each pixel on TFT display is driven by a thin film transistor, The TFT display is a type of active matrix liquid crystal display device.
Description | 1.57 inch TFT LCD display |
Outline size | 23.4*38.5*2.2mm |
Active area | 21.36*33.79mm |
Resolution | 200*320 |
Driving IC | ST7789 |
Interface | SPI |
Driving Voltage | 2.8V |
| Viewing direction | All |
Backlight | LED*3,white |
Operating temperature | -20~70 ℃ |
Storage temperature | -30~80 ℃ |
The full name of TFT is Thin Film Transistor. Each pixel on TFT display is driven by a thin film transistor, The TFT display is a type of active matrix liquid crystal display device.
Description | 1.57 inch TFT LCD display |
Outline size | 23.4*38.5*2.2mm |
Active area | 21.36*33.79mm |
Resolution | 200*320 |
Driving IC | ST7789 |
Interface | SPI |
Driving Voltage | 2.8V |
| Viewing direction | All |
Backlight | LED*3,white |
Operating temperature | -20~70 ℃ |
Storage temperature | -30~80 ℃ |
